Capacity

60g

Readability (d)

0.001g

Verification (e)

0.01g

Repeatability (Standard Deviation)

0.001g

Linearity

+/- 0.002g

Tare Range

-60g

Stabilization Time (typical)

< 3s

Calibration Masses

10g | 20g | 50g

Accuracy Class

II

Weighing Units

Grams (g) | Milligram (mg) | Kilogram (kg) | Carat (ct) | Pound (lb) | Ounce (oz) | Ounce Troy (ozt) | Penny Weight (pwt) | Grain (gr) | Newton (N)

Analyzer Resolution

0.01%

Moisture Measurement Accuracy

1% (0.01 to 0.5g sample)

0.1% (0.5 to 5g sample)

0.01% (> 5g sample)

Moisture Measurement Repeatability

+/-0.1% (2g sample)

+/-0.04% (5g sample)

Maximum Drying Temperature

250°C

Sampling Time

1 sec. to 180 sec.

Maximum Drying Time

10 Hours

Drying Power

500W (2 x 250W)

Halogen Size

188 mm, 250W

Warm-up Time

Approximately 180 sec.

Pan Dimension

3.5 in (90 mm) Stainless Steel

Drying Chamber Dimensions

4.2 x 0.8 in (108 x 20 mm)

Analyzer Dimension

8.4 x 13.5 x 7.8 in (215 x 345 x 200 mm)

Operating Temperature

+18°C to +33°C

RS232 Port

Bidirectional – Standard

USB Port

Type B

PS2 Port

Standard

Ethernet Port

Optional

Wi-Fi

Optional

Power Supply

110VAC, 60Hz

Display Type

Graphical LCD

Display Size

5.06 x 1.56 in (128.5 x 39.6 mm)

Analyzer Net Weight

15.43lbs

Printing

Yes

Warranty

36 Months
